Dump trailers come in many different sizes with various features for specific jobs. They are used primarily in the farming and industrial industries. They are great for hauling dirt, gravel, rocks, and other material. For jobs that are too big for a pickup truck and too small for a full sized dump truck, the perfect solution is a dump trailer. Dump trailers are the perfect piece of equipment to haul your material to the right place at the right time. Let's take a closer look at the sizes and features of dump trailers.
Size
One of the biggest mistakes people make when buying trailers is choosing the right size. You don't want to overpay and get too big of a trailer, and you don't want to risk damage by getting too small of a trailer. This is where a sales professional can guide you on the proper fit.
When it comes to sizes for dump trailers, there are generally two sizes. Smaller and larger. The smaller sized dump trailers are in the neighborhood of 4x6 or 5x8. They can carry somewhere around 1,800 lbs or a gross vehicle weight (GVW) of 3,000 (this will vary according to manufacturer specs). The larger sized dump trailers can be as big as 12,14 or 20 feet in length and carry up to 20,000 lbs!
The smaller dump trailers are single axle whereas the larger ones are double axle.
Features
As the size varies so will the features from manufacturer to manufacturer. Here are some common features you will find on most high quality dump trailers.
Heavy duty sides and floors
Two way gates
Ramps
LED lights
Adjustable bulldog coupler
Integrated battery charger
Steel locking toolbox
Reinforced bed sides
Self contained hydraulic units
Side extensions
Tarp ready
Manufacturers
We at Trailersforless.com carry a wide range of dump trailers from many different manufacturers. With 2 locations in central Georgia, we are one of the largest dump trailer dealers in the entire Southeast. Our manufacturers for dump trailers are names such as Anderson Manufacturing, Load Trail, Big Tex Trailers, PJ Trailers and more. Call our office today at 1-888-461-3033 and let one of our qualified professionals help you find a dump trailer to fit your needs. Don't forget we offer financing!
7X16 7 ton dump 4' sides Iron Bull
Iron Bull DTB dump trailer beast models are built to work. Every DTB sits atop of a dual layer of 6" I-beam weighing in at 12 pounds per ft main frame construction. That's 24 lbs/ft of pure steel putting maximum strength into the most critical part of your trailering system. Our 83" wide 14k bumper pull is by far our most popular model. With two 7k axles and tons of standard features, This model is a perfect fit for the contractor or weekend warrior.
DESCRIPTION
These show-stopper dump trailers are built to haul. 14,000-21,000 lbs of GVWR and are equipped with enough lifting power to ensure you can always get your job done. Each Iron Bull 83 wide dump comes equipped standard with an industry best 7 gauge floor and 24" high 10 gauge sides with 7 machined breaks that will not bend, bow, or buckle, even under the most demanding conditions....
Iron bull 5x10 3 ton dump trailer
DESCRIPTION
These dump trailers feature top of the line brake axles and radial tires, providing a solid foundation for each Iron Bull dump trailer, and ample grip for stopping power. Sherwin-Williams Powdura powder coat gives each trailer a rugged finish with a showroom shine. Hydraulic cylinders are the muscle for each Iron Bull dump trailer and remote operated hydraulic pumps feed the beast. This trailer comes with lifetime LEDs provided by TecNic lighting - and all units are powered by an Interstate deep cycle battery. Each Iron Bull Trailer also comes equipped with a standard tarp kit, stake pockets, locking pump box, 5 position adjustable coupler, multi-function gate and 110v wall outlet charging receptacle for your battery. Our 60" wide 7k bumper pull dump may be small, but it's full of might. With two 3500lb axles and tons of standard features, this model is a great addition to any job site or home.
7x14 7 ton dump Iron Bull By Nor Star
DTB14
14,000 lb GVWR Tandem Axle Dump Trailer
Iron Bull DTB dump trailer beast models are built to work. Every DTB sits atop of a dual layer of 6" I-beam weighing in at 12 pounds per ft main frame construction. That's 24 lbs/ft of pure steel putting maximum strength into the most critical part of your trailering system. Our 83" wide 14k bumper pull is by far our most popular model. With two 7k axles and tons of standard features, This model is a perfect fit for the contractor or weekend warrior.
DESCRIPTION
These show-stopper dump trailers are built to haul. 14,000-21,000 lbs of GVWR and are equipped with enough lifting power to ensure you can always get your job done. Each Iron Bull 83 wide dump comes equipped standard with an industry best 7 gauge floor and 24" high 10 gauge sides with 7 machined breaks that will not bend,...
6X12 5 ton High side dump trailer
Telescopic cylinder lift
Two (2) 5200 Lb Cambered Braking Axles
235/85/R16 10 ply tires
48" Side Wall Height
Rear Double Swing Gate with Cam Bar Lock
10 Gauge Steel Floor
8-K Top Wind Jack
2"X 4" Tubular Steel Top Rails
Five Stake Pockets on each Side, Three across front (Total
Electric Hydraulic Single Cylinder Lift
Up and Down Powered Hydraulic Pump
Interstate Deep Cycle 12 Volt Marine Battery
12 Volt-5-amp Charger
Lockable Battery & Pump Box
25' Remote Control Electrical Cable
All Lighting LED
Manual Operated Trap
Three (3) Year Factory Warranty
Posted 4-19-2023 Call Scottie for price and availibility 706-318-2543
Covered Wagon 6x12 5 ton dump 4' sides
6X12 Heavy Duty 10400 Lb GVWR Prospector Dump Trailer
Two (2) 5200 Lb Cambered Braking Axles
ST225/75R-15 Steel Belted Radial Tires on 6 Lug Steel Wheels
48" Side Wall Height
Rear Double Swing Gate with Cam Bar Lock
10 Gauge Steel Floor
8-K Top Wind Jack
2"X 4" Tubular Steel Top Rails
Five Stake Pockets on each Side, Three across front (Total
Electric Hydraulic Single Cylinder Lift
Up and Down Powered Hydraulic Pump
Interstate Deep Cycle 12 Volt Marine Battery
12 Volt-5-amp Charger
Lockable Battery & Pump Box
25' Remote Control Electrical Cable
All Lighting LED
Manual Operated Trap
Three (3) Year Factory Warranty
Call Scottie for price and availability
706-318-2543
7 x 16 7 ton gooseneck dump trailer
2-7000# brake axles
10 gauge floor and sides
2 way gate
slide under ramps
2' sides
4 d- rings
led lights
powder coated finish
stake pockets to build up sides.
battery with 110volt charger
powered up and down
Call Scottie for price and availability 706-318-2543
10K LOW PROFILE TANDEM AXLE DUMP TRAILER
When the job is already tough, the loading and unloading doesn't have to be. This heavy-duty dump trailer features a low profile, making loading and dumping as easy as it can be. When you need to haul heavy loads to or from your worksite safely, and dump the material right where you want it, look no further.
6x10 5 ton
24" sides
Loading ramps
4 HD D rings
Two way gate
MODEL INFORMATION:
OVERALL W X L:92" x 173"BED W X L:72" x 120"GATE W X H:73" x 20"EMPTY WEIGHT:2,350 lbs.PAYLOAD CAPACITY:7,640 lbs.FLOOR:Steel, 11 Ga.GVWR:9,990 lbs.AXLE 2:5,000 lb. Drop Axle w/ BrakeBREAKAWAY KIT INCLUDED:YesLEAF SPRINGS:5FLOOR:5" ChannelUPRIGHT HEIGHT:IntegratedTOP RAIL:24" H, 14 Ga. SteelTONGUE EXTENSION:2-5/16" A-FrameCOUPLER:5,000 lb. Rated Top WindJACK:ST225X15TIRES:White ModWHEELS:SteelFENDER WELLS,Combination Spreader/Tail GateHYDRAULIC CYLINDER:powered up and down110v chargerHYDRAULIC OPERATION:12v with Remote Control
Call Scottie for price and availability 706-318-2543
PJ 83X14 7 TON Pro-lift dump
Telescoping cylinder
40°
Dump Angle
Standard Configuration Specs
These are the default specs that are included on the base configuration of this model.
Standard Features
Trailer Specs
Dimensions
Lengths 14', 16'
Bed Width 83"
Bed Height 28"
Weight Ratings
GVWR 14,000 lbs.
GAWR 7,000 lb. x (2) G.A.W.R.
Finish
Type Powdercoat
Prep Acid Wash, Sandblast
Colors Black
Warranty
Axle Warranty 5 year Dexter Axle Warranty
Trailer Warranty Three (3) Year Frame/One (1) Year Limited Warranty
Tongue
Coupler
Standard Coupler BP 2-5/16"" Adjustable (14,000 lb.)
Jacks
Front Jack Drop Leg Jack (12,000 lb.)
Toolbox
Toolbox Lockable Toolbox (Houses Battery and Pump)
Tounge
Type 8" x 13 lb. I-beam Tongue
Length
(Bumper Pull) 4' 10" (58")
Safety System
Breakaway System Defender 2 Electric...
